Yamato ADL311-A 是我們最小巧且經濟實惠的噴霧乾燥系統,可輕鬆將液體樣品微粉化為粉末。此噴霧乾燥裝置具有輪式高度移動性,也可用作桌上型裝置。Yamato 的 ADL311-A 噴霧乾燥機配備獨特的噴嘴冷卻機構、脈衝噴射機構和噴嘴門環,可協助您實現穩定且一致的噴霧乾燥。
我們所有的噴霧乾燥機都經過精心設計,可滿足您對各種食品、製藥和其他小規模應用的基本需求。使用我們的 ADL311-A 噴霧乾燥機,以經濟的價格獲得高性能和移動式噴霧乾燥的組合。
Yamato ADL311-A 是我們最小巧且經濟實惠的噴霧乾燥系統,可輕鬆將液體樣品微粉化為粉末。此噴霧乾燥裝置具有輪式高度移動性,也可用作桌上型裝置。Yamato 的 ADL311-A 噴霧乾燥機配備獨特的噴嘴冷卻機構、脈衝噴射機構和噴嘴門環,可協助您實現穩定且一致的噴霧乾燥。
我們所有的噴霧乾燥機都經過精心設計,可滿足您對各種食品、製藥和其他小規模應用的基本需求。使用我們的 ADL311-A 噴霧乾燥機,以經濟的價格獲得高性能和移動式噴霧乾燥的組合。
Model | ADL311-A |
---|---|
Temp. adjusting unit setting range | 40 to 220deg.C (inlet temperature), 0 to 60deg.C (outlet temperature) |
Temperature adjusting accuracy | Inlet temperature±1deg.C |
Drying air amount adjusting range | 0〜0.7m3/min |
Spray air pressure adjusting range | 0〜0.3MPa |
Liquid sending pump flow rate range | 0〜26 ml/min |
Spray air line washing function | Spraying at the nozzle tip, manual pulse jet system |
External output | Inlet temperature, outlet temperature, temperature outlet (4-20 mA) |
Temperature adjusting device | PID digital temperature adjusting device |
Touch panel | Blower, heater, liquid sending pump, pulse jet switch, error display |
Control select switch | Inlet temperature, outlet temperature control switch (Outlet temp. control is conditional.) |
Temperature sensor | K-thermocouple |
Heater | 2.0 kW (at 200V) to 2.88 kW (at 240V) |
Liquid sending | Fixed amount peristaltic pump |
Spraying air pump | Spraying air compressor (sold separately) is used |
Service outlet | For stirrer: AC100V, MAX2A |
Suction blower | Bypass blower |
Filter | Suction filter, exhaust filter |
Recovery of solvent | – |
Spray nozzle cooling mechanism | Connector: nipple x 2, O.D.:φ10.5 mm |
Spray air connection diameter | Nipple diameter:φ7 mm |
Spray air pressure | Bourdon tube: 0.3 MPa |
Exhaust connecting diameter | φ50mm |
Safety function | Inlet/outlet temperature overheat, sample feed reverse rotation mechanism, over current electric leakage breaker, nozzle connection error |
External dimensions(W×D×H mm) | 580×420×1125mm |
Power Source | AC220V AC220V Single phase |
Weight | 80kg |
